LED DRIVER SCC-200
Ordering code: SCC200XXX (XXX - number of model)
The LED DRIVER SCC-200 is programmable driver with multiple dimming capability 0-10 V or PWM and adjustable output current by software.
- One-way powerline communication QM-50-SSI3
- Built-in module for smart dimming and power line control
- Adjustable output current by software
- Protections: SCP/OVP/OTP
- IP67 design for indoor and outdoor applications
| Typ | Model | Output voltage (V) | Rated Current (A) |
|---|---|---|---|
| SCC 75W | 041 | 20-41 | 4.88-6.67 |
| 062 | 38-62 | 3.23-5.00 | |
| 096 | 48-96 | 2.1-3.00 | |
| 143 | 70-143 | 1.40-2.10 | |
| 191 | 96-191 | 1.05-1.50 | |
| 286 | 143-286 | 0.7-1.05 |
Note: Possibility to adjust output parameters according to customers requirement
| Parameter | Value | Parameter | Value |
|---|---|---|---|
| Input voltage | AC 220 V ~ 240 V | IP rating | IP67 |
| Input frequency | 50 Hz | Operating temperature | -40~+60 °C |
| Rated power |
200 W |
Maximum case temperature | +90 °C |
| AC Current (Max.) | 1.2 A max. at AC 230 V | Weight | 1000±100g |
| Current Tolerance | <5% | Dimensions (LxWxH) | 194x66.2x38.5 mm |
