LED DRIVER SCC-75

LED DRIVER SCC-75

Ordering code: SCC75XXX (XXX - number of model)

The LED DRIVER SCC-105 is programmable driver with multiple dimming capability 0-10 V or PWM and adjustable output current by software.

  • One-way powerline communication QM-50-SSI3
  • Built-in module for smart dimming and power line control
  • Adjustable output current by software
  • Protections: SCP/OVP/OTP
  • IP67 design for indoor and outdoor applications
Typ Model Output voltage (V) Rated Current (A)
SCC 75W 041 20-41 1.83-2.67
062 38-62 1.22-1.88
150 54-108 0.7-1.05
Parameter Value Parameter Value
Input voltage AC 220 V ~ 240 V IP rating IP67
Input frequency 50 Hz Operating temperature -40~+60 °C
Rated power

105 W

Maximum case temperature +90 °C
AC Current (Max.) 1.0 A max. at AC 230 V  Weight 500±50g
Current Tolerance <5% Dimensions (LxWxH) 129x66.17x36.85 mm
